The largest banger/ bucket setups commonly available. As such these require quite large dabs for effective use, much smaller than around 0.1g will provide a sub-par experience.
These 25mm and 30mm axial e-nails with thick wall quartz bangers are mains powered beasts so are for home use only. They have accurate and stable temperature control so provide excellent quality vapour. Quartz is one of the preferred materials to vape from, being inert it provides clean accurate flavour profiles, this is enhanced here by the accurate temperature control. We rate this setup as one of the best for large dabs and sessions.
The e-nail setup consists of a PID controller, a 220V UK plug and a 220V round e-nail coil. These are used to heat the included quartz Banger (14mm male joint) with quartz insert with a high level of consistency. The quartz insert is included as they make for easier cleaning since the insert takes the majority of the residues. So that can be swabbed out, removed and torch cleaned if required (on a heat proof surface) or even switched over for a fresh one, requiring for less regular full cleans of the banger.
General vaping temperature range on this device is between 200-280C without an insert and around 220C-300C with an Insert. Due to heat losses in the system (between banger and insert), temperatures when using the inset need to be set a little higher. Please note that this suggested range is a conservative temperature range as you can always turn it up if you want thicker clouds, but once your dab is burnt it's gone! So we tend to suggest starting at slightly lower temperatures then turning it up if desired.
The average banger temperature (across the base and walls, which do not heat at the same speed, the walls heat faster as it's coil heated) will tend to sit at around 25C lower than the set temperature on the controller (depending on the exact tolerance of the banger and coil, this can vary a little - a slightly looser fit between banger and coil requires a slightly higher set temperature.). Different concentrates also vaporize at different temperature ranges so there is no one right answer as to the best temperature. It's partly down to the specific setup tolerances, partly down to personal preference and partly down to the specific concentrate you're vaping!
My personal setup is usually set to around 260C when using the insert and 240C without, though this can vary by 20-30C depending on the type of concentrate being used and the desired output I'm after, so please take this just as a general guide, you may like it hotter... and that's fine too!
Heat time for this setup takes around 5 minutes to stabilize, ensure you give it at least this long so that the temperature throughout the banger can stabilize. Whenever possible heat your insert with the banger and never drop (always carefully lower) your insert into the banger, if you're using one. When using the insert please allow it to pre-heat for a little longer as there are always heat losses in systems like this. If you're starting a fresh session with a clean or replacement insert in the hot banger, give it around 5 minutes for the insert to heat before loading your dab in.
The PID Controller has an auto shut-off timer set to two hours. This timer can be increased to five hours, decreased to one hour or turned off entirely so your banger is always kept at the desired temperature (instructions below).
As the temperature is constant this setup is ideal for session use, load it up and repeatedly hit it until the concentrate has been vapourised. Then wipe and repeat as desired.
In The Box
- Enail controller box (1 year warranty - CE, ROHS certified)
- 1.8m 220V UK power cable with UK 3-pin plug
- 1.2m Kevlar lined cable with axial E-nail (Stainless Steel coil) (6 month warranty)
- 25mm or 30mm Quartz Banger
- 14.4mm glass joints
- Quartz insert for Banger
- Directional Bubble Carb Cap
- 2 x Cotter pins to hold Banger in Place
- (Bubbler not included, displayed for illustrative purposes only)
Optional Parts
- Extended reach spinning Carb Cap - ideal for use with insert.
- Non stick SiC (Silicon Carbide) Inserts
- Quartz Inserts
For easy handling of your banger inserts we suggest using our Silicone Tipped Reverse Clamp Tweezers.
PID Controller Instructions
- Hold the central button for 5 seconds to turn on or off
- Use the +/- buttons to adjust the temperature
- When switched on, press the central button five times to access auto-off timer
- Adjust with +/- from 0-5. 0 switches the timer off or select 1-5 hours
- Celcius/Fahrenheit adjustment - Hold down + button for 5 seconds while the controller is switched off. Then press the + button again to change between C and F. Press the central button to exit.
Warranty is only for manufacture defects not misuse or incidental damage. Manufactured by SZ Crossing. Only use compatible parts, do not use with enails from different manufacturers together as they may cause damage to the controller or coil. Confirmed compatability with Cannabis Hardware, Auber, Disorderly conduction and 710coils
- Pin 1 is AC live line, pin 2 is AC zero line, pin 3 is temp positive, then 4 is temp negative and pin 5 is ground
Caution: These have an exposed heater coil which gets very hot. Do not touch the coil or quartz banger during use, always allow time for it to cool before handling and never leave it unattended while on. Keep away from water, high humidity, pets and children (common sense stuff!).
Don't apply force when clipping the cotter pin to the bottom of the banger, it doesn't need to go all the way to the end of the clip, just to the central part to hold it in place (shown in last image). If you push it too far the quartz at the base of the banger will snap!
