Introducing the new Dual Coil PID Controller from Crossing, compatible with the full range of SZ Crossing coils! This is a regular PID controller with a live temperature display and screen on the front. The controller also allows the temperature to be adjusted in one Fahrenheit increments giving you full control of the temperature. It has two separate coil plugs on the back, each with their own power switch and temperature control screen on the front, allowing you to run two different setups with different temperatures at the same time!
Specifications
- Dual Coil PID Controller
- Live Temperature Display
- 1 Fahrenheit Resolution/Increments
- Red Digital Display
- Two Power Switches on Back
- Grippy Silicone Feet
- UK 3-pin Plug Included (220v)
- 110v/220V Compatible Controller
- ROHS and CE Certified
- 1 Year Warranty Against Defects
- Confirmed compatibility with Crossing, Vapvana, CH, Auber, Disorderly Conduction (DC) and 710 Coils
- Pin 1 is AC live line, pin 2 is AC zero line, pin 3 is temp positive, then 4 is temp negative and pin 5 is ground
- Approx 140 wide x 135 deep x 40mm high
We also have the Micro E-nail PID Controller which works a little differently along with the single coil version of this PID Controller available here.
These come to us without instructions. As such they are shipped out without instructions! Simply turn on/off using the switch on the back and adjust the temperature with the up/down buttons on the front.
To adjust the temperature on this controller, you just need to press the up or down button to adjust, then leave it for a few seconds to set. Do not press the set button as this is for accessing the back end set up menu for the controller! Adjusting these settings will change how the PID controller functions which can mess up the temperature control and damage the coils.
Customer Reviews
A fantastic dual PID controller with a great feel to it, responsive and temperatures on point. I had an issue with one of the switches on the back, Matt rapidly sorted this problem out for me. Great PID sold by a fantastic company RVS keep up the great work that you do 😎
Great PID, displays temp in real time, really solid feel. Had a slight problem with one of the switches on the back but rec vapes sorted it by the next day, excellent service.
